Steel NM400
NM steels are a group of high-strength steels with increased wear resistance, produced in China. NM steel is an analogue of Hardox and is almost as good as the Swedish steel grade in terms of characteristics. Rolled metal products made of NM steel have increased hardness and strength. This makes it suitable for use in conditions of high wear and abrasive effects. Therefore, NM steel is widely used in the mining, construction and agricultural industries.
Application areas of special steel NM:
- Road, agricultural and construction machinery: crushers, screeners, loading devices, measuring bins, skip hoists, cutting edges, conveyors, buckets, knives, gears, chain wheels,
- Road construction, bridge construction, underground tunnel construction; railway construction, carriage building;
- Trucks, metalworking machines, bulldozers, excavators, electric cars, dump trucks, loaders and removable equipment for them;
- Pulp pipeline systems;
- Screw conveyors, presses, etc.
NM steel sheets are produced in such grades as NM360, NM400, NM450, NM500, etc. The chemical composition of the steel includes manganese, which provides high strength, wear resistance, and resistance to impact loads. Additional alloying elements improve the main operational properties.
NM400 steel is the most common of the NM series of abrasion-resistant sheet materials. 400 is the Brinell hardness value HB (the hardness value is generalized, the internal hardness range of NM400 is 380-420). Due to its high toughness and excellent weldability, this type of steel is often used as a structural and abrasion-resistant sheet material at the same time. The hardness of a product made of NM 400 steel is usually between 360 and 450HB.
Chemical composition of steel NM400
| Steel grade | WITH | Si | Mn | P | S | Cr | Ni | Mo | B |
| NM 400 | 0.24 max |
0.50 max |
1.60 max |
0.025 max |
0.015 max |
0.40- 0.80 |
0.20- 0.50 |
0.20- 0.50 |
0.005 max |
Mechanical properties of NM400 steel
| Steel grade | Yield strength (MPa) | Tensile strength (MPa) | Elongation A5 (%) | Impact test | Hardness | |
| NM 400 | min 1000 |
min 1250 |
min 10 |
(°C) -20 |
J/cm2 (min) 30 | HBW 360-440 |
Sheet sizes and price of NM400 steel
| Steel grade | Thickness, mm | Length, mm | Width, mm | Price |
| NM400 | 570 – 640 | 1000-12000 | 1000-3000 | Specify |
You can buy NM400 steel with delivery from the manufacturer in our company. You can order NM400 sheet steel by phone, email or through the order form on the website.
You can find out the price by sending a request to our email [email protected] or by WhatsApp the manager at +86 13037600603
